锥(及
密55° 封非 胶密 管封 接管 头螺 公纹 制) 螺接 纹头 |
标记示例(1)公称通径
DN6的锥密封胶管接头55°非密封管螺纹接头: 锥接头6/G1/8 (2)公称通径DN10,端连接螺纹d=M14×1.5的 锥密封胶管公制螺纹接头:锥接头10/M14×1.5 |
公称
通径 DN |
(a)公制
螺纹 |
(b)55°
圆锥管 螺纹接头 |
(a)、(b)
|
||||||
|
接头d
|
d1
|
do
|
S
|
l1
|
l2
|
L
|
重量
kg |
||||
|
4
|
M10×1
|
G1/8
|
M16×1.5
|
2.5
|
18
|
12
|
20
|
31
|
0.03
|
||
|
6
|
M10×1
|
G1/8
|
M18×1.5
|
3.5
|
18
|
12
|
20
|
31
|
0.04
|
||
|
8
|
M10×1
|
G1/8
|
M20×1.5
|
5
|
18
|
12
|
21
|
34
|
0.06
|
||
|
10
|
M14×1.5
|
G1/4
|
M22×1.5
|
7
|
24
|
14
|
22
|
35
|
0.08
|
||
|
10
|
M18×1.5
|
G3/8
|
M24×1.5
|
8
|
27
|
14
|
25
|
39
|
0.10
|
||
|
15
|
M22×1.5
|
G1/2
|
M30×2
|
10
|
30
|
16
|
26
|
40
|
0.14
|
||
|
20
|
M27×2
|
G3/4
|
M33×2
|
13
|
41
|
18
|
30
|
46
|
0.32
|
||
|
20
|
M27×2
|
G3/4
|
M36×2
|
17
|
41
|
18
|
37
|
52
|
0.56
|
||
|
25
|
M33×2
|
G1
|
M42×2
|
19
|
55
|
20
|
38
|
55
|
0.71
|
||
|
32
|
M42×2
|
G11/4
|
M45×2
|
24
|
55
|
22
|
41
|
58
|
0.78
|
||
|
40
|
M48×2
|
G11/4
|
M56×2
|
30
|
60
|
24
|
44
|
63
|
0.96
|
||
|
50
|
M60×2
|
G2
|
M68×2
|
40
|
75
|
26
|
50
|
71
|
1.14
|
||
|
锥(及
密60° 封非 胶密 管封 接管 头螺 55°纹公制) 螺接 纹头 |
标记示例(1)公称通径
DN6的锥密封胶管接头55°非密封管螺纹接头: 锥接头6/G1/8 (2)公称通径DN10,端连接螺纹d=M14×1.5的 锥密封胶管公制螺纹接头:锥接头10/M14×1.5 |
公称
通径 DN |
(a)55°密封
管螺纹接头 |
(b)60°密封
管螺纹接头 |
(a)、(b)
|
|||||||
|
d
|
l1
|
d
|
l1
|
d1
|
do
|
S
|
l2
|
L
|
重量
kg |
|||
|
4
|
R1/8
|
4
|
Z1/8
|
4.572
|
M16×1.5
|
2.5
|
18
|
17
|
29
|
0.03
|
||
|
6
|
R1/8
|
4
|
Z1/8
|
4.572
|
M18×1.5
|
3.5
|
18
|
17
|
29
|
0.04
|
||
|
8
|
R1/8
|
6
|
Z1/8
|
4.572
|
M20×1.5
|
5
|
18
|
18
|
30
|
0.06
|
||
|
10
|
R1/4
|
6.4
|
Z1/4
|
5.080
|
M22×1.5
|
7
|
24
|
22
|
34
|
0.08
|
||
|
10
|
R3/8
|
6.4
|
Z3/8
|
6.096
|
M24×1.5
|
8
|
27
|
24
|
38
|
0.10
|
||
|
15
|
R1/2
|
8.2
|
Z1/2
|
8.128
|
M30×2
|
10
|
30
|
27
|
41
|
0.14
|
||
|
20
|
R3/4
|
9.5
|
Z3/4
|
8.611
|
M33×2
|
13
|
41
|
28
|
44
|
0.32
|
||
|
20
|
R3/4
|
9.5
|
Z3/8
|
8.611
|
M36×2
|
17
|
41
|
38
|
56
|
0.56
|
||
|
25
|
R11
|
10.4
|
Z11
|
10.16
|
M42×2
|
19
|
55
|
39
|
59
|
0.71
|
||
|
32
|
R111/4
|
12.7
|
Z111/4
|
10.66
|
M45×5
|
24
|
55
|
44
|
64
|
0.78
|
||
|
40
|
R111/2
|
12.7
|
Z111/2
|
10.66
|
M56×2
|
30
|
60
|
46
|
68
|
0.96
|
||
|
50
|
R12
|
15.9
|
Z12
|
11.07
|
M68×2
|
40
|
75
|
1.14
|
||||
|
胶
管 接 头 推 荐 长度(参考) |
装配长L
|
320
|
360
|
400
|
450
|
500
|
560
|
630
|
710
|
800
|
900
|
1000
|
1120
|
1250
|
1400
|
|
偏差
|
+20
0 |
+25
0 |
+30
0 |
||||||||||||
|
装配长L
|
1600
|
1800
|
2000
|
2240
|
2500
|
2800
|
3000
|
4000-5000
|
≥5000
|
||||||
|
偏差
|
+40
0 |
+50
0 |
|||||||||||||
